不锈钢门套线包边的做法
用冲击电钻在门四周大洞眼,并插入木楔。
Use an impact electric drill to make a big hole around the door and insert a wooden wedge.
将15厘大芯板(或夹板)靠墙侧进行防潮处理(刷光油2遍后在贴珍珠棉)。用钉枪校正固定后,再用铁钉加固。门套线条打底用9厘夹板。打底夹板外侧用实木线条收口。合页位置加板衬固或封两层15厘大芯板。
Conduct moisture-proof treatment on the side of 15 cm large core board (or splint) close to the wall (apply pearl cotton after brushing varnish twice). After correction and fixation with nail gun, it shall be reinforced with iron nails. The door pocket line is primed with 9 cm plywood. The outer side of the backing splint shall be closed with solid wood lines. Two layers of 15 cm core plates shall be lined or sealed at the hinge position.
门套与门扇相合之处到进门边的侧面用9厘夹板做止口板,止口深度与门的厚度相同。
9 cm plywood is used as the stop plate from the joint of the door pocket and the door leaf to the side of the entrance door, and the stop depth is the same as the thickness of the door.
面板用白乳胶涂匀后贴于打第大芯板及止口板上,并用不锈钢蚊钉适当加固。
The panel shall be coated with white emulsion and pasted on the first core plate and stop plate, and properly reinforced with stainless steel mosquito nails.
门套线条宽度一般为60mm—80mm.厚度
The width of door pocket line is generally 60mm-80mm thickness
厨卫门套线条里侧用不锈钢(哑光)线条为宜。
Stainless steel (matte) lines should be used on the inner side of the kitchen and bathroom door cover.
门套及门窗套垂直、水平误差不超过2mm(2m以上不超过3mm)对角线误差不超过3mm(2m以上不超过
The vertical and horizontal error of door pocket and door and window pocket shall not exceed 2mm (not more than 3mm above 2m), and the diagonal error shall not exceed 3mm (not more than 2m)
门套两侧墙与门套之间距离在门套线条不能压住接缝时,宜先用水泥砂浆挂钢钉封平(用板定模灌浆)干燥后方可封板打第,在门套线条能压住接缝时可用板封龙骨结构。
When the distance between the walls on both sides of the door pocket and the door pocket cannot press the joint, it is advisable to seal the plate with cement mortar hanging steel nails (grouting with plate fixed formwork) before drying. When the door pocket line can press the joint, the keel structure can be sealed with plate.
单面门套用9厘板打底(凸窗应注意窗帘位置)。其他与双面门套同。入户大门可封单边实木线条门套。
Single sided door pocket shall be bottomed with 9 cm board (attention shall be paid to the curtain position for bay window). Others are the same as double-sided door pocket. The entrance door can be sealed with a single side solid wood line door pocket.
窗套不宜包台面,台面用大理石铺贴(防盗网宜在窗套面板封后制作)。单面门套:在原来有门的基础上起装饰作用,不起承受门的力量。
The window cover should not cover the table top, and the table top should be paved with marble (the anti-theft net should be made after the window cover panel is sealed). Single sided door pocket: it plays a decorative role on the basis of the original door, and can not bear the strength of the door.
